Grooving Tool Holder
Your Professional Grooving Tool Holder Supplier
Kunshan Meiyaxing Hardware Machinery Co., Ltd. is a company specializing in the production and sales of metal cutting tools. With more than 20 years of experience, we set new technology, high-end machinery and tool manufacturers as one, to provide customers with quality tools, is a direct branch of Hong Kong Meiya International Trading company. Since the establishment of the company - always uphold the "quality", "professional" and "efficient" business philosophy. Founded the MANF brand, and with Japan Kyocera, Sumitomo, Mitsubishi, Taiwan ECHAIN, Germany C.P.T and other international brands trade cooperation.
Why Choose Us
Reliable Product Quality
We are proud of our high quality, cost-effective and good service, and have won the praise of customers in various industries such as aviation, medical equipment, automobile manufacturing, mold processing and electronic technology.
Good Service
High-quality after-sales service, tracking usage, and positive feedback. Rapid response within 24 hours.
Product Application
Our widely used in aviation, medical equipment, automobile manufacturing, mold processing and electronic technology and many other industries.
Technical Team
We not only provide high quality and efficient cutting tools, but also have a superb technical team to provide professional and detailed processing solutions.
Advantages of Grooving Tool Holder
Improved Precision And Accuracy
Grooving tool holders are designed to hold cutting tools securely, ensuring precise and accurate machining operations. This results in high-quality grooves and features with tight tolerances.
Extended Tool Life
Specialized grooving tool holders, such as those with coolant channels or multi-edge inserts, can help extend tool life by reducing heat and wear. This leads to lower tooling costs and increased productivity.
Enhanced Productivity
Grooving tool holders enable efficient and rapid machining of grooves and features, reducing cycle times and increasing overall productivity in machining operations.
Versatility And Adaptability
Adjustable grooving tool holders and specialized inserts allow for versatility and adaptability in machining applications, accommodating a wide range of groove sizes and types.
Reduced Setup Time
Using grooving tool holders with quick-change capabilities can reduce setup time, allowing for faster transitions between different machining tasks and increasing efficiency.
Specification
|
Type |
Insert |
Specification |
Screw |
Wrench |
||||||
|
W |
B |
H |
L |
H1 |
F |
Tmax |
||||
|
MGEHR/L1616-2 |
MGMN200 |
2 |
16 |
16 |
100 |
16 |
16 |
16 |
M5x20 |
L4 |
|
MGEHR/L2020-2 |
2 |
20 |
20 |
125 |
20 |
20 |
16 |
M6x20 |
L5 |
|
|
MGEHR/L1616-3 |
MGMN300 MGGN300 MRMN300 |
3 |
16 |
16 |
100 |
16 |
16 |
20 |
M5x20 |
L4 |
|
MGEHR/L2020-3 |
3 |
20 |
20 |
125 |
20 |
20 |
20 |
M6x20 |
L5 |
|
|
MGEHR/L2525-3 |
3 |
25 |
25 |
150 |
25 |
25 |
20 |
|||
|
MGEHR/L3232-3 |
3 |
32 |
32 |
170 |
32 |
32 |
20 |
|||
|
MGEHR/L1616-4 |
MGMN400 MGGN400 MRMN400 |
4 |
16 |
16 |
100 |
16 |
16 |
20 |
M5x20 |
L4 |
|
MGEHR/L2020-4 |
4 |
20 |
20 |
125 |
20 |
20 |
20 |
M6x20 |
L5 |
|
|
MGEHR/L2525-4 |
4 |
25 |
25 |
150 |
25 |
25 |
20 |
|||
|
MGEHR/L3232-4 |
4 |
32 |
32 |
170 |
32 |
32 |
20 |
|||
|
MGEHR/L2020-5 |
MGMN500 MGGN500 MRMN500 |
5 |
20 |
20 |
125 |
20 |
20 |
25 |
||
|
MGEHR/L2525-5 |
5 |
25 |
25 |
150 |
25 |
25 |
25 |
|||
|
MGEHR/L3232-5 |
5 |
32 |
32 |
170 |
32 |
32 |
25 |
|||
|
MGEHR/L2525-6 |
MGMN600 MGGN600 MRMN600 |
6 |
25 |
25 |
150 |
25 |
25 |
25 |
||
|
MGEHR/L3232-6 |
6 |
32 |
32 |
170 |
32 |
32 |
25 |
|||
Types Of Grooving Tool Holder
These are the most basic and widely used grooving tool holders. They are designed to hold a single cutting tool and are suitable for creating simple grooves and notches.
These tool holders can accommodate multiple cutting edges on a single insert, allowing for extended tool life and reduced tool change frequency. They are ideal for high-volume production environments.
Adjustable grooving tool holders allow for precise adjustment of the cutting tool position, enabling the creation of grooves with varying widths and depths. They are versatile and suitable for a wide range of applications.
These tool holders are equipped with built-in coolant channels to deliver cutting fluid directly to the cutting edge. This helps reduce heat and extends tool life, especially in high-speed machining operations.
In addition to standard types, there are specialized grooving tool holders designed for specific applications, such as creating O-ring grooves, thread grooves, or keyways. These tool holders are tailored to meet the unique requirements of particular machining tasks.
Applications of Grooving Tool Holder
O-ring Grooves
Creating O-ring grooves in cylindrical components is a common application in industries such as automotive and aerospace. Grooving tool holders with precision inserts are used to achieve the required groove dimensions for O-rings, ensuring proper sealing and functionality.
01
Keyways And Splines
In the production of gears, shafts, and couplings, keyways and splines are essential features. Grooving tool holders with specialized inserts are employed to create these features accurately, ensuring proper fit and function.
02
Threading And Parting
Threading and parting operations are common in machining. Grooving tool holders with threading inserts are used to create threads on cylindrical parts, while parting tools are used to separate or cut off sections of a workpiece.
03
Creating Grooves For Seals And Bearings
Grooves for seals and bearings are essential in various machinery components. Grooving tool holders with precision inserts are used to create these grooves, ensuring proper fit and function for seals and bearings.
04
Manufacturing Of Precision Components
In high-precision machining applications, such as aerospace and medical device manufacturing, grooving tool holders are used to create intricate grooves and features with tight tolerances.
05
The Customization Process
Consultation & Inquiry: Contact our experienced sales or engineering team to discuss your specific needs and application requirements. You can use the contact form below.
Technical Specification & Design: Provide us with detailed technical drawings, specifications, or even sketches of your desired tool holder. Our engineers can also assist with the design process if needed.
Quotation & Lead Time: Based on your specifications, we will provide you with a detailed quotation and estimated lead time for manufacturing.
Manufacturing & Quality Control: Once you approve the quotation, your custom tool holder will be manufactured using our state-of-the-art equipment and undergo rigorous quality control checks to ensure it meets your exact specifications.
Delivery & Support: Your custom tool Grooving Tool Holder will be carefully packaged and shipped to your location. Our team is also available for ongoing technical support and assistance.
