MGEHR MGEHL External Grooving Tool Holders



Product Name: MGEHR MGEHL External Grooving Tool Holders

Brand name: MANF

Place of origin: China

Raw material: 40CrMo

Clamping Type: External Grooving Tool Holders

Diameter: 16-32mm

Length: 100-170mm

Color of surface: Black

Insert: MGMN MGGN

Usage: CNC lathe, CNC machine tool

Insert processing materials: Stainless steel, steel, non-ferrous metals, high heat-resistant materials, difficult-to-process materials, high-temperature alloys, etc.





MGEHR1616-2 MGEHL1616-2

MGEHR2020-2 MGEHL2020-2

MGEHR1616-3 MGEHL1616-3

MGEHR2020-3 MGEHL2020-3

MGEHR2525-3 MGEHL2525-3

MGEHR3232-3 MGEHL3232-3

MGEHR1616-4 MGEHL1616-4

MGEHR2020-4 MGEHL2020-4

MGEHR2525-4 MGEHL2525-4

MGEHR3232-4 MGEHL3232-4

MGEHR2020-5 MGEHL2020-5

MGEHR2525-5 MGEHL2525-5

MGEHR3232-5 MGEHL3232-5

MGEHR2525-6 MGEHL2525-6

MGEHR3232-6 MGEHL3232-6







Type	Insert	Specification							Screw	Wrench
		w	b	h	L	h1	f	Tmax
MGEHR/L1616-2	MGMN200	2	16	16	100	16	16	16	M5x20	L4
MGEHR/L2020-2		2	20	20	125	20	20	16	M6x20	L5
MGEHR/L1616-3	MGMN300 MGGN300 MRMN300	3	16	16	100	16	16	20	M5x20	L4
MGEHR/L2020-3		3	20	20	125	20	20	20	M6x20	L5
MGEHR/L2525-3		3	25	25	150	25	25	20
MGEHR/L3232-3		3	32	32	170	32	32	20
MGEHR/L1616-4	MGMN400 MGGN400 MRMN400	4	16	16	100	16	16	20	M5x20	L4
MGEHR/L2020-4		4	20	20	125	20	20	20	M6x20	L5
MGEHR/L2525-4		4	25	25	150	25	25	20
MGEHR/L3232-4		4	32	32	170	32	32	20
MGEHR/L2020-5	MGMN500 MGGN500 MRMN500	5	20	20	125	20	20	25
MGEHR/L2525-5		5	25	25	150	25	25	25
MGEHR/L3232-5		5	32	32	170	32	32	25
MGEHR/L2525-6	MGMN600 MGGN600 MRMN600	6	25	25	150	25	25	25
MGEHR/L3232-6		6	32	32	170	32	32	25





MGEHR MGEHL external grooving tool holder, the tool holder adopts quenching and hardening process, high hardness and not easy to deform, can be used for strong cutting installation, saving man-hours, high efficiency and low consumption. The screw compression method is adopted, and the inserted seam is highly effective in earthquake resistance. It can be processed laterally and has no vibration knife lines. The chamfering of the handle makes it easier to carry out process upgrades and reinforcements. Using the free forging process, the impact force eliminates defects such as shrinkage cavities, shrinkage porosity, and pores. , so that the tool blank has higher mechanical properties. Currently in the Chinese market, our MGEHR external groove tool holders enjoy a high reputation and are worthy of customers' trust.



MANF brand is one of the largest manufacturers and distributors of MGEHR outer diameter grooving tool holders in China. MANF is a company dedicated to building a professional CNC tool supply platform, making processing simple and making products perfect. We have assembled a group of experienced design and R&D teams. We have many engineers in the research institute who are engaged in R&D and design work. They make products seriously and control every step so that our products are exported to many countries and regions such as Europe, America, Japan and South Korea. area. A large portion of our sales come from overseas, so we understand the needs of overseas customers better. Use mature transportation channels to deliver goods to customers quickly and accurately.





We use DHL, UPS, Fedex, China Post and other transportation methods, convenient and accurate delivery to you.
